Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670039691 | Rear Right Silencer |
$1,710.40 |
|
|
| 2 | M-670039690 | Rear Left Silencer |
$1,718.68 |
|
|
| 3 | M-675000059 | Small Block |
$15.73 |
|
|
| 4 | M-670001494 | Central Support |
$35.48 |
|
|
| 5 | M-670154406 | Hot-End (Scr) |
$2,695.46 |
|
|
| 7 | M-675000705 | Screw |
$1.37 |
|
|
| 8 | M-670031936 | Rh Rear Silencer Support |
$48.15 |
|
|
| 9 | M-670039693 | Rh Front Bracket Exhaust Pip |
$32.01 |
|
|
| 10 | M-675000328 | Nut |
$1.36 |
|
|
| 11 | M-670034561 | Lh Rear Silencer Support |
$18.32 |
|
|
| 12 | M-670039692 | Lh Front Bracket Exhaust Pip |
$32.01 |
|
|
| 14 | M-675000089 | Washer |
$0.96 |
|
|
| 15 | M-670006145 | Clamp |
$38.33 |
|
|
| 16 | M-670034586 | Central Support |
$25.16 |
|
|
| 17 | M-675000487 | Screw Tc/Ie M8X20 Ros.P.Imp. |
$1.44 |
|
|
| 19 | M-675000328 | Nut |
$1.36 |
|
|
| 20 | M-670178878 | Rear Rh Compl Bracket |
$19.04 |
|
|
| 21 | M-670178879 | Rear Lh Compl Bracket |
$19.04 |
|
|
| 23 | M-675000761 | Screw |
$2.89 |
|
