Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 5 | M-670034505 | Special Screw |
$2.54 |
|
|
| 6 | M-675000020 | Lower Shield Fastening Clip |
$7.17 |
|
|
| 7 | M-675000326 | Screw |
$1.98 |
|
|
| 8 | M-670100069 | Clip |
$2.54 |
|
|
| 10 | M-670032341 | Damper |
$49.34 |
|
|
| 11 | M-670032916 | Lh Bracket |
$11.70 |
|
|
| 12 | M-670032915 | Rh Bracket |
$11.70 |
|
|
| 13 | M-670065941 | Rh Top Front Grille Bumper |
$69.38 |
|
|
| 14 | M-670034559 | Screw |
$2.11 |
|
|
| 16 | M-670065953 | Lh Top Front Grille Bumper |
$69.38 |
|
|
| 17 | M-675000323 | Rivet |
$1.88 |
|
|
| 19 | M-670014562 | Fixing Button. |
$3.07 |
|
|
| 20 | M-670003766 | Screw |
$5.03 |
|
|
| 23 | M-670034505 | Special Screw |
$2.54 |
|
|
| 25 | M-670033498 | Air Duct |
$117.56 |
|
|
| 27 | M-675000228 | Screw |
$2.28 |
|
|
| 29 | M-670005535 | Block |
$7.53 |
|
|
| 30 | M-675000588 | Screw |
$1.02 |
|
|
| 31 | M-670039369 | Front Bumper Adhesive M161 |
$32.87 |
|
|
| 36 | M-670065942 | Central Top Front Grille Bum |
$56.86 |
|
|
| 41 | M-670065943 | Front Skid Plate (Chrome) |
$240.01 |
|
|
| 44 | M-670034560 | Clip |
$2.45 |
|
|
| 46 | M-670071795 | Radar Trim |
$406.09 |
|
