Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-673010434 | Rh Body Side Frame Assembly |
$849.12 |
|
|
| 2 | M-673005674 | Upper Rh Headlight Housing G |
$71.76 |
|
|
| 3 | M-673010792 | Lower Rh Headlight Housing G |
$45.80 |
|
|
| 6 | M-673009409 | Lower Rear Guard Assembly |
$366.16 |
|
|
| 7 | M-673013833 | Rear Cross Member Assembly |
$107.95 |
|
|
| 8 | M-673005680 | Rh. Rear Insert |
$30.68 |
|
|
| 9 | M-670106337 | Cpl Rh Tailight Base |
$389.11 |
|
|
| 10 | M-673010435 | Lh Body Side Frame Assembly |
$849.12 |
|
