Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670003474 | Lever |
$11.37 |
|
|
| 2 | M-670037585 | Cavo Bowden Park Release |
$113.46 |
|
|
| 4 | M-670035011 | Trailing Cable |
$107.59 |
|
|
| 6 | M-670003473 | Mounting Bracket |
$49.15 |
|
|
| 8 | M-675000166 | Screw |
$1.48 |
|
|
| 9 | M-675000178 | Washer |
$1.21 |
|
|
| 10 | M-675000180 | Screw |
$1.21 |
|
|
| 14 | M-670003475 | Nut |
$1.69 |
|
|
| 15 | M-675000191 | Screw |
$2.00 |
|
|
| 18 | M-675000434 | Screw |
$4.58 |
|
|
| 20 | M-673002716 | Park Release Lever (No Cable |
$21.45 |
|
|
| 23 | M-670035043 | Clip M161 |
$3.06 |
|
|
| 24 | M-670035041 | Bracket M161 |
$4.52 |
|
|
| 27 | M-670105809 | Adapter |
$27.58 |
|
|
| 28 | M-675000811 | Screw |
$1.38 |
|
|
| 29 | M-670035713 | Fastening Screw |
$1.71 |
|
