Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670108662 | Rh Filter Box Assembly |
$231.42 |
|
|
| 2 | M-670001545 | Air Filter |
$57.73 |
|
|
| 4 | M-670108664 | Lh Filter Box Assembly |
$179.99 |
|
|
| 5 | M-675000776 | Screw |
$2.06 |
|
|
| 6 | M-670005249 | Bushing |
$14.16 |
|
|
| 7 | M-670031925 | Upper Rh Air Intake Sleeve |
$129.52 |
|
|
| 8 | M-670031926 | Upper Lh Air Intake Sleeve |
$129.52 |
|
|
| 11 | M-670038730 | Filter Box Bracket |
$15.56 |
|
|
| 12 | M-675000135 | Clip |
$0.96 |
|
|
| 13 | M-670005248 | Circlip |
$94.29 |
|
|
| 18 | M-670102965 | Rh Clean Air Intake Sleeve B |
$14.23 |
|
|
| 19 | M-670102966 | Lh Clean Air Intake Sleeve B |
$3.09 |
|
|
| 21 | M-675000308 | Screw |
$1.61 |
|
|
| 23 | M-670103700 | Lh Clean Air Intake Sleeve |
$298.08 |
|
|
| 24 | M-670103697 | Lower Rh Air Intake Sleeve M |
$320.94 |
|
