Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670174900 | Tube |
$345.81 |
|
|
| 2 | M-670174891 | Tube |
$122.45 |
|
|
| 3 | M-670174894 | Tube |
$103.84 |
|
|
| 4 | M-670174892 | Tube |
$112.66 |
|
|
| 5 | M-670009820 | A.C. Condenser |
$806.23 |
|
|
| 6 | M-670038668 | Pressostat |
$60.51 |
|
|
| 7 | M-675001009 | Ac Compressor |
$249.80 |
|
|
| 8 | M-670174647 | Heat Shield |
$18.48 |
|
|
| 10 | M-675000122 | O-Ring 1/2 - 1234Yf |
$7.87 |
|
|
| 11 | M-670005087 | Plug |
$16.60 |
|
|
| 12 | M-675000315 | Nut |
$1.77 |
|
|
| 13 | M-675000456 | Screw |
$4.69 |
|
|
| 14 | M-675001096 | Nut |
$0.69 |
|
|
| 16 | M-675000902 | Threaded Stud |
$2.84 |
|
|
| 17 | M-675001090 | Nut |
$1.05 |
|
|
| 18 | M-673000010 | Dehydrator Filter |
$234.13 |
|
|
| 19 | M-675001019 | Screw |
$2.45 |
|
|
| 25 | M-675000249 | Screw |
$1.41 |
|
|
| 27 | M-675000123 | O-Ring 3/4 - 1234Yf |
$8.30 |
|
|
| 29 | M-675000121 | O-Ring 3/8 - 1234Yf |
$6.23 |
|
|
| 30 | M-675000121 | O-Ring 3/8 - 1234Yf |
$6.23 |
|
|
| 31 | M-675000123 | O-Ring 3/4 - 1234Yf |
$8.30 |
|
|
| 34 | M-675000119 | O-Ring 68X187 |
$1.98 |
|
|
| 36 | M-670100149 | Lhd Upper Plenum Acoustic Li |
$7.98 |
|
|
| 37 | M-670039321 | Lhd Lower Plenum Acoustic Li |
$17.26 |
|
|
| 38 | M-675000315 | Nut |
$1.77 |
|
