Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670052921 | Oil Pump |
$567.20 |
|
|
| 2 | M-670050469 | Screw |
$1.39 |
|
|
| 3 | M-670050186 | Bar |
$11.17 |
|
|
| 4 | M-675001417 | Seeger |
$1.25 |
|
|
| 5 | M-670051233 | Screw |
$7.43 |
|
|
| 6 | M-670052759 | Screw |
$9.22 |
|
|
| 7 | M-670051157 | Oil Pump Gear |
$84.46 |
|
|
| 8 | M-675001404 | Seeger |
$1.36 |
|
|
| 9 | M-670051232 | Pad |
$11.86 |
|
|
| 10 | M-670053547 | Bracket |
$4.65 |
|
|
| 11 | M-670054085 | Tube |
$56.38 |
|
|
| 12 | M-670050147 | Screw |
$2.63 |
|
|
| 13 | M-670053958 | Oil Filter |
$217.48 |
|
|
| 14 | M-670052849 | Oil Filter Cartridge |
$58.30 |
|
|
| 15 | M-670050119 | Engine Oil Filter Gasket |
$25.01 |
|
|
| 16 | M-670053348 | Oil Pressure Sensor |
$90.45 |
|
|
| 17 | M-670051108 | Screw |
$2.30 |
|
|
| 18 | M-670050169 | Screw |
$13.84 |
|
|
| 19 | M-675000106 | Washer |
$1.63 |
|
|
| 20 | M-675002074 | Oil Sensor |
$38.37 |
|
|
| 21 | M-670053666 | Cable |
$17.99 |
|
