Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 8 | M-675001651 | Screw |
$3.00 |
|
|
| 9 | M-670218092 | Front Bumper Fascia |
$38.41 |
|
|
| 11 | M-670157179 | Right Bracket Right Bumper |
$4.22 |
|
|
| 12 | M-670157216 | Upper Fixing Bracket Left Bu |
$4.22 |
|
|
| 15 | M-675000635 | Pad |
$8.75 |
|
|
| 16 | M-670174532 | Bracket |
$18.46 |
|
|
| 17 | M-675001390 | Screw |
$2.03 |
|
|
| 18 | M-675001883 | Screw |
$1.34 |
|
|
| 20 | M-675001674 | Fastening Clip |
$1.15 |
|
|
| 21 | M-675002035 | Bracket Screw M6 |
$1.64 |
|
|
| 22 | M-670157346 | Front Lower Fascia Extension |
$31.55 |
|
|
| 23 | M-675001049 | Screw |
$1.10 |
|
|
| 24 | M-675000294 | Pin |
$2.47 |
|
|
| 26 | M-675001884 | Screw |
$1.34 |
|
|
| 27 | M-670292889 | Pad |
$4.13 |
|
|
| 28 | M-670198009 | Left Bumper Air Duct |
$62.65 |
|
|
| 29 | M-670198008 | Right Bumper Air Duct |
$62.65 |
|
|
| 31 | M-675000326 | Screw |
$1.95 |
|
|
| 32 | M-675001930 | Screw |
$0.79 |
|
