Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-980145370 | Cpl Rear Bumper |
$1,789.82 |
|
|
| 2 | M-80063800 | Rh Bracket For Cpl Rear Bump |
$107.37 |
|
|
| 3 | M-80084300 | R.H.Bracket |
$216.86 |
|
|
| 4 | M-80084400 | L.H.Bracket |
$248.76 |
|
|
| 5 | M-980145031 | Rear Bumper Fastening Trim P |
$89.77 |
|
|
| 6 | M-16082704 | Screw. |
$1.81 |
|
|
| 7 | M-80442500 | R.H.Bracket |
$21.62 |
|
|
| 8 | M-80442900 | Lh.Bracket |
$21.62 |
|
|
| 9 | M-14775211 | Screw For Steering Wheel |
$2.09 |
|
|
| 10 | M-12642801 | Washer |
$1.20 |
|
|
| 11 | M-14370571 | Bracket |
$1.12 |
|
|
| 12 | M-80305300 | R.H.Rear Side Absorber |
$30.39 |
|
|
| 13 | M-80305400 | L.H.Rear Side Absorber |
$30.39 |
|
|
| 16 | M-80269600 | Elastic Clip |
$5.16 |
|
|
| 17 | M-51810310 | Screw. |
$3.72 |
|
|
| 18 | M-312320384 | Gasket |
$1.12 |
|
|
| 19 | M-83534000 | Rh Side Grilltrofeo |
$140.32 |
|
|
| 20 | M-83534100 | Lh Side Grilltrofeo |
$634.65 |
|
|
| 21 | M-83534200 | Central Grilltrofeo |
$403.96 |
|
|
| 22 | M-15688807 | Screw 35X13 |
$3.93 |
|
