Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-213635 | Electro-Injector Ev14 |
€254,25 |
|
|
| 2 | M-133902 | O-Ring D.7.8X3.6 |
€8,65 |
|
|
| 3 | M-144730 | Injector Retaining Clip |
€4,88 |
|
|
| 4 | M-224573 | Timing Sensor |
€43,77 |
|
|
| 5 | M-239242 | Spark Plug -Ngk- |
€24,45 |
|
|
| 6 | M-281449 | Ignition Coil High End |
€129,86 |
|
|
| 7 | M-245268 | Eldor Coils Injection Wiring |
€1.120,58 |
|
|
| 8 | M-243890 | Control Unit Ignition |
€1.195,40 |
|
|
| 9 | M-230760 | Rpm Sensor With Bank |
€84,54 |
|
|
| 10 | M-231616 | Screw |
€1,78 |
|
|
| 11 | M-246805 | Detonation Sensor Ks4 |
€85,05 |
|
|
| 12 | M-246804 | Detonation Sensor Ks4 |
€211,56 |
|
|
| 13 | M-246802 | Detonation Sensor Ks4 |
€211,56 |
|
|
| 14 | M-246803 | Detonation Sensor Ks4 |
€86,00 |
|
|
| 15 | M-231629 | Socket Head Screw With Washe |
€2,09 |
|
|
| 16 | M-201672 | Oil Pressure Transmitter. |
€5,07 |
|
|
| 17 | M-231616 | Screw |
€1,78 |
|
|
| 18 | M-10440990 | Pipe Bracket With Sheath |
€1,46 |
|
|
| 19 | M-10441190 | Bracket With Sheath |
€0,95 |
|
|
| 20 | M-81222700 | Bracket |
€44,25 |
|
|
| 21 | M-11625624 | Screw. |
€2,09 |
|
|
| 22 | M-243937 | Bracket |
€11,13 |
|
|
| 23 | M-14039614 | Nut |
€1,10 |
|
|
| 24 | M-243938 | Heat Shield |
€98,44 |
|
|
| 25 | M-14039614 | Nut |
€1,10 |
|
|
| 26 | M-243290 | Plug |
€18,40 |
|
