| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-270983 | Complete Differential |
€3.170,17 |
||
| 2 | M-15977921 | Screw |
€5,32 |
||
| 3 | M-11194174 | Washer. |
€2,32 |
||
| 7 | M-270625 | Cpl. Axle Shaft |
€577,38 |
||
| 8 | M-181910 | Screw |
€2,90 |
||
| 9 | M-222679 | Plate |
€3,09 |
||
| 10 | M-198514 | Heat Protection. |
€13,09 |
||
| 11 | M-240022 | R.H.Front Bracket |
€286,96 |
||
| 12 | M-240023 | L.H.Front Bracket |
€286,96 |
||
| 13 | M-240024 | Rear Bracket |
€752,17 |
||
| 14 | M-238620 | Differential Support Pad |
€30,08 |
||
| 14 | M-238620 | Differential Support Pad |
€30,08 |
||
| 14 | M-238620 | Differential Support Pad |
€30,08 |
||
| 15 | M-271187 | Flanged Hex Head Screw M10X1 |
€8,31 |
||
| 15 | M-271187 | Flanged Hex Head Screw M10X1 |
€8,31 |
||
| 15 | M-271187 | Flanged Hex Head Screw M10X1 |
€8,31 |
||
| 16 | M-229202 | Centring Dowel D13 |
€2,90 |
||
| 16 | M-229202 | Centring Dowel D13 |
€2,90 |
||
| 16 | M-229202 | Centring Dowel D13 |
€2,90 |
||
| 17 | M-189097 | Differential Outlet Shaft |
€1.377,74 |
||
| 17 | M-189097 | Differential Outlet Shaft |
€1.377,74 |
||
| 18 | M-181618 | Rh Rotating Sealing Ring As5 |
€51,00 |
||
| 19 | M-181617 | Lh Rotating Sealing Ring As5 |
€45,79 |
||
| 20 | M-184995 | Ball Bearing D. 50X80X16 |
€56,78 |
||
| 20 | M-184995 | Ball Bearing D. 50X80X16 |
€56,78 |
||
| 21 | M-184994 | Circlip Type Sw D.50 |
€4,54 |
||
| 21 | M-184994 | Circlip Type Sw D.50 |
€4,54 |
||
| 22 | M-185723 | Seeger Ring D. 80 |
€5,22 |
||
| 23 | M-218086 | Propeller Shaft Connection F |
€179,75 |
||
| 24 | M-183967 | Ring Nut For Main Shaft |
€58,15 |
||
| 25 | M-221062 | Sealing Ring 50X82X12 |
€60,96 |
||
| 26 | M-271172 | O-Ring D.178X34 |
€7,44 |
||
| 27 | M-271177 | Magnetic Cap 18X1.5 |
€40,96 |
||
| 28 | M-271178 | Level Cap M22X15 |
€28,69 |
||
| 29 | M-10263460 | Gasket 22- 28X 1.5 |
€1,35 |
||
| 30 | M-197797 | Breather |
€21,45 |
||
| 31 | M-14468781 | O-Ring D.221.84X3 |
€40,48 |
||
| 32 | M-16287321 | Flanged Hex Head Screw M8X30 |
€9,78 |
||
| 33 | M-10263460 | Gasket 22- 28X 1.5 |
€1,35 |
||
| 34 | M-284616 | Axle Specer |
€24,25 |
