Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670109996 | Water Radiator |
€607,75 |
|
|
| 2 | M-670001324 | Cpl Radiator Upper Rh Suppor |
€21,99 |
|
|
| 3 | M-670107327 | Rubber Bushing For Water Rad |
€57,32 |
|
|
| 4 | M-670001323 | Cpl Radiator Upper Lh Suppor |
€21,99 |
|
|
| 5 | M-670005012 | Upper Profile |
€56,76 |
|
|
| 6 | M-670005011 | Lower Profile |
€43,70 |
|
|
| 8 | M-670005263 | Air Pipe Gaiter On Cover |
€92,92 |
|
|
| 9 | M-670003405 | Clip |
€38,18 |
|
|
| 11 | M-670004142 | Air Conveyor |
€167,45 |
|
|
| 13 | M-673000009 | Bleeding / Degas Kit |
€45,91 |
|
|
| 14 | M-673000013 | Motor Fastening Screw |
€33,76 |
|
|
| 16 | M-673000017 | Temperature Sensor Protectio |
€80,87 |
|
|
| 17 | M-675000354 | Screw |
€2,29 |
|
|
| 18 | M-673000015 | Cable Fastening Clip |
€42,32 |
|
|
| 19 | M-675000545 | Rubber Bushing |
€2,40 |
|
|
| 21 | M-670030111 | Fastening Plug |
€18,58 |
|
