Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670034967 | Gear Box Oil Exchanger |
$186.57 |
|
|
| 2 | M-670154670 | Support Plate |
$18.44 |
|
|
| 3 | M-675000191 | Screw |
$2.00 |
|
|
| 4 | M-675000565 | Washer |
$1.11 |
|
|
| 5 | M-675000365 | Screw |
$2.64 |
|
|
| 6 | M-670154650 | Gearbox Oil Delivery Pipe |
$332.55 |
|
|
| 7 | M-670154669 | Pipes Bracket |
$10.13 |
|
|
| 8 | M-675001032 | Screw |
$1.26 |
|
|
| 9 | M-675001126 | Bracket |
$8.09 |
|
|
| 10 | M-675000794 | Flanged Nut |
$1.50 |
|
|
| 11 | M-675001091 | Bracket |
$7.23 |
|
|
| 12 | M-675000397 | Screw |
$9.12 |
|
|
| 13 | M-673013792 | O-Ring 1/44572/81 |
$9.92 |
|
|
| 14 | M-14457081 | Gasket |
$2.09 |
|
|
| 15 | M-670003311 | O-R Gasket |
$1.13 |
|
