The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 3 | M-675000294 | Pin |
$2.52 |
|
|
| 9 | M-673002033 | Luggage Carpet Internal Door |
$11.27 |
|
|
| 13 | M-670008994 | Rh Pad (Luggage Compt.) |
$13.64 |
|
|
| 17 | M-670172654 | Luggage Comp. Pad |
$73.46 |
|
|
| 18 | M-675000231 | Lh Air Outlet Plate |
$13.52 |
|
|
| 19 | M-670006256 | Epb Pad |
$75.77 |
|
|
| 20 | M-675000294 | Pin |
$2.52 |
|
|
| 21 | M-670006115 | Lh Pad (Luggage Compt.) |
$15.15 |
|
|
| 24 | M-675000310 | Screw |
$1.50 |
|
|
| 25 | M-675000137 | Door Lamp White |
$3.73 |
|
|
| 27 | M-670005931 | Plug |
$4.58 |
|
|
| 28 | M-673002365 | Luggage Compt. Pins |
$8.55 |
|
|
| 32 | M-673005736 | Luggage C. Protection Cover |
$2.46 |
|
|
| 33 | M-673007156 | Clip |
$2.46 |
|
|
| 34 | M-673007155 | Clip |
$2.46 |
|
|
| 35 | M-673007154 | Luggage Net |
$52.30 |
|
|
| 36 | M-670030890 | Rear Trim |
$10.93 |
|
