Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670003474 | Lever |
$11.23 |
|
|
| 2 | M-670105722 | Cable |
$118.83 |
|
|
| 4 | M-670003469 | Cable |
$81.99 |
|
|
| 5 | M-670003471 | Retaining Clip |
$2.68 |
|
|
| 6 | M-670030127 | Plate |
$6.52 |
|
|
| 8 | M-675000166 | Screw |
$1.46 |
|
|
| 9 | M-675000178 | Washer |
$1.19 |
|
|
| 10 | M-675000180 | Screw |
$1.19 |
|
|
| 13 | M-670031740 | Gear Selector (Lhd) |
$778.24 |
|
|
| 14 | M-670003475 | Nut |
$1.67 |
|
|
| 15 | M-675000382 | Screw |
$2.39 |
|
|
| 16 | M-675000272 | Retaining Clip |
$5.01 |
|
|
| 17 | M-670035716 | Fastening Screw |
$1.55 |
|
|
| 18 | M-675000434 | Screw |
$4.53 |
|
|
| 20 | M-673002716 | Park Release Lever (No Cable |
$21.19 |
|
|
| 21 | M-675000526 | Screw |
$1.82 |
|
|
| 22 | M-673002679 | Leaf Spring To Unlock Park-C |
$21.03 |
|
|
| 23 | M-673002680 | Rivet |
$6.41 |
|
|
| 28 | M-675000811 | Screw |
$1.36 |
|
