The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 2 | M-980000966 | Rh Handle Gasket |
$41.00 |
|
|
| 5 | M-384500396 | Door Lock Handle Connect.Tie |
$8.26 |
|
|
| 6 | M-46401658 | Screw With Incorp.Washer |
$2.19 |
|
|
| 7 | M-60594692 | Rubber Bushing |
$26.08 |
|
|
| 8 | M-16284914 | Screw For Exterior Door H |
$2.46 |
|
|
| 9 | M-67237000 | Rh Door Int. Opening Bowden |
$32.24 |
|
|
| 11 | M-14572587 | Cable And Line Ret.Clip 1/5. |
$1.35 |
|
|
| 13 | M-15624311 | Rivet For Bracket On Inte |
$2.32 |
|
|
| 14 | M-67236800 | Rh Door Internal Handle |
$869.58 |
|
|
| 15 | M-388300615 | Switch |
$57.96 |
|
|
| 16 | M-82377992 | Retaining Clip |
$0.87 |
|
|
| 18 | M-60624899 | Rh Door Stopping Tie-Rod Gas |
$2.19 |
|
|
| 19 | M-11620021 | Screw For Complete Door H |
$2.19 |
|
|
| 22 | M-10902434 | Hex Head Screw M 6X20 |
$1.65 |
|
|
| 23 | M-11197774 | Washer |
$2.24 |
|
|
| 24 | M-11586024 | Screw For Complete Door H |
$5.74 |
|
|
| 25 | M-382500536 | Hinge Plate Thick. 1Mm |
$95.71 |
|
|
| 26 | M-60624898 | Rh Door Stopping Tie-Rod Gas |
$2.19 |
|
|
| 27 | M-67420200 | White |
$1.87 |
|
|
| 28 | M-384500390 | Int.Lock Pawl Connect.Tie-Ro |
$5.60 |
|
|
| 31 | M-387700406 | Shim For Door Glass Rear Run |
$18.31 |
|
|
| 32 | M-13271617 | Tcic Pz Screw M4X6 |
$1.35 |
|
|
| 33 | M-14496207 | Split Washer D. 4.30- 9 X0 |
$1.06 |
|
|
| 35 | M-15689907 | Tbic S-Thread.Screw M8X25 |
$1.35 |
|
|
| 37 | M-14573280 | Cables Retaining Clip |
$1.12 |
|
