Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-179140 | Cpl Power Unit |
$2,606.62 |
|
|
| 2 | M-980001155 | Ppv Valve Kit Dx0017627A |
$634.49 |
|
|
| 3 | M-980001154 | Qpv Valve Kit Dx0017486A |
$634.49 |
|
|
| 4 | M-980001156 | Ag P.U. Pressure Sensor 0016 |
$285.20 |
|
|
| 5 | M-185891 | Cpl Power Unit Fastening Mou |
$1,068.61 |
|
|
| 6 | M-179143 | Reservoir |
$1,146.20 |
|
|
| 7 | M-179211 | Accumulator Duct |
$261.26 |
|
|
| 8 | M-14058411 | Nut |
$1.72 |
|
|
| 9 | M-16100814 | Nut For Rear Differential |
$1.72 |
|
|
| 10 | M-12601374 | Washer |
$1.36 |
|
|
| 12 | M-16297024 | Flanged Hex Head Screw M6X18 |
$2.46 |
|
|
| 13 | M-184269 | Cpl Pipe From Accum.To Valve |
$106.07 |
|
|
| 14 | M-14301924 | Screw |
$2.46 |
|
|
| 15 | M-12601274 | Washer |
$1.38 |
|
|
| 16 | M-213264 | Hydraulic Pump |
$1,659.88 |
|
|
| 17 | M-185186 | Pipe From Pump To Valve Unit |
$120.81 |
|
|
| 18 | M-184968 | F1 Gearbox Oil Tank |
$612.88 |
|
|
| 19 | M-980001147 | Cpl Tank Plug F1 Kb04L0 / E |
$9.71 |
|
|
| 20 | M-980001148 | Oil Level Gauge Kb04R0 / E |
$69.64 |
|
|
| 21 | M-185952 | Gearbox Oil Tank Bracket |
$195.60 |
|
|
| 22 | M-980001157 | Pump Fastening Kit 0017482.A |
$265.77 |
|
|
| 23 | M-186298 | Tank Support Strip |
$77.02 |
|
|
| 24 | M-183718 | Rubber Gasket |
$13.64 |
|
|
| 25 | M-10902124 | Screw |
$1.72 |
|
|
| 26 | M-12601274 | Washer |
$1.38 |
|
|
| 27 | M-185070 | Pipe From Power Unit To Oil |
$563.77 |
|
|
| 28 | M-14305724 | Screw |
$1.72 |
|
|
| 29 | M-12601274 | Washer |
$1.38 |
|
|
| 30 | M-10441790 | Bracket With Sheath |
$1.13 |
|
|
| 31 | M-161490 | Screw Collar D.12-20X9 |
$4.58 |
|
|
| 32 | M-179338 | Tank Fuel Pipe To Motor-Driv |
$188.58 |
|
|
| 33 | M-13000390 | Screw Collar |
$1.81 |
|
|
| 34 | M-980001159 | P.U. Pump Union Kit Dx0017 |
$240.63 |
|
|
| 35 | M-188459 | Cpl Filter Oil |
$7.10 |
|
|
| 36 | M-14066021 | Low S-Lock.Hex.Nut With Flan |
$4.44 |
|
|
| 37 | M-585410200 | Studs For Head Cover And Pip |
$21.43 |
|
|
| 38 | M-14306524 | Screw |
$2.09 |
|
|
| 39 | M-10441390 | Bracket With Sheath |
$1.72 |
|
|
| 40 | M-12601279 | Washer |
$1.36 |
|
|
| 41 | M-15896214 | Nut |
$1.08 |
|
|
| 42 | M-162606 | Clip |
$2.19 |
|
|
| 43 | M-14058411 | Nut |
$1.72 |
|
|
| 45 | M-16285924 | Screw |
$1.53 |
|
|
| 47 | M-12601174 | Washer |
$1.59 |
|
|
| 48 | M-14496324 | Split Washer D. 5.30X9.55 |
$1.73 |
|
|
| 49 | M-15896414 | Hex. Nut M5X4 |
$1.72 |
|
|
| 50 | M-186906 | Bracket |
$25.84 |
|
