| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | L-4ML805594 | Plastic Front-End |
€605,00 |
||
| 2 | L-4M0805201 | Bracket Kuehlerlager Unten |
€28,30 |
||
| 2 | L-4M0805202 | Bracket Kuehlerlager Unten |
€28,30 |
||
| 3 | L-4ML805133 | Side Member |
€59,20 |
||
| 3 | L-4ML805134 | Side Member |
€50,70 |
||
| 4 | L-4ML805262 | Cross Member,Front |
€337,00 |
||
| 5 | L-4M0121131D | Coolant V8Hsi Hwk Zwk |
€205,50 |
||
| 6 | L-4ML121286 | Air Duct Element |
€40,75 |
||
| 7 | L-4ML121283 | Air Duct Part |
€37,43 |
||
| 7 | L-4ML121284 | Air Duct Part |
€37,19 |
||
| 8 | L-4ML121285 | Air Duct Element, |
€56,72 |
||
| 9 | L-4ML805607 | Headlamp Mounting |
€52,20 |
||
| 9 | L-4ML805608 | Headlamp Mounting |
€52,20 |
||
| 10 | L-4M0806185A | Slide Elements Gleitkufe Linke Se |
€12,95 |
||
| 10 | L-4M0806186A | Slide Elements |
€12,95 |
||
| 11 | L-8K0805399B | Retaining Part |
€2,15 |
||
| 12 | L-N90993602 | Hexalobular Socketm6X25-S11 |
€0,99 |
||
| 13 | L-N91132602 | Hexalobular Socketm6X28-S23 |
€2,05 |
||
| 16 | L-867129669 | Grommet |
€1,70 |
||
| 17 | L-1K0129734B | Spacer |
€5,65 |
||
| 18 | L-N10413408 | Hexalobular Socketm6X25 |
€0,64 |
||
| 19 | L-N90993603 | Hexalobular Socketm6X25-S11 |
€1,15 |
||
| 20 | L-N91196402 | Hexagon Flange M10X35 |
€2,60 |
||
| 21 | L-N91262801 | Hexalobular Socketm6X64-S23 |
€2,30 |
||
| 22 | L-N91215101 |
12-Point Socket
|
€1,60 |
||
| 23 | L-N10690201 | Hexagon Flange M8X70 |
€2,50 |
||
| 24 | L-N91081302 | Washer |
€2,25 |
||
| 25 | L-4ML807109 | Bumper Bar,Front |
€711,00 |
||
| 25 | L-4ML807109B | Bumper Bar,Front |
€1.520,00 |
||
| 26 | L-4M0802037B | Side Member Vorn Unten |
€120,00 |
||
| 26 | L-4M0802038C | Side Member Vorn Unten |
€117,00 |
||
| 27 | L-4M0802441 | Reinforcement |
€7,55 |
||
| 27 | L-4M0802442 | Reinforcement |
€7,50 |
||
| 28 | L-4M0803329A | Support Untere Lastebene |
€89,60 |
||
| 28 | L-4M0803330B | Support Untere Lastebene |
€89,60 |
||
| 29 | L-N91096801 |
Hexalobular Socketm6X20
|
€1,15 |
||
| 30 | L-N10576702 | Hexagon Head Bolt M8X75-S1-L |
€2,35 |
||
| 31 | L-N10664801 | 12-Point Socket M8X20 |
€1,20 |
