Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | L-0P2109611A | Exhaust Valve |
$45.43 |
|
|
| 2 | L-06M109601D | Intake Valve |
$46.88 |
|
|
| 4 | L-06M109423A | Hydraulic Lash Adjuster |
$85.52 |
|
|
| 5 | L-06E109641A | Valve Spring Plate |
$16.01 |
|
|
| 6 | L-06E109623AD | Valve Spring |
$15.38 |
|
|
| 7 | L-0P2109623 | Valve Spring |
$9.57 |
|
|
| 8 | L-0P2109629 | Spring Plate |
$3.13 |
|
|
| 9 | L-06M109259P | Magnet |
$52.10 |
|
|
| 10 | L-06M103555C | Shield |
$8.59 |
|
|
| 11 | L-06M906048F | Valve |
$116.04 |
|
|
| 12 | L-06M907601D | Pulse Generator |
$95.15 |
|
|
| 13 | L-036109651A | Valve Lock |
$4.00 |
|
|
| 14 | L-036109675A | Valve Stem Seal |
$17.23 |
|
|
| 15 | L-06L109675C | Valve Stem Seal |
$9.40 |
|
|
| 16 | L-04E906145 | Seal Ring |
$5.05 |
|
|
| 17 | L-N91126601 | Hexalobular Socketm6X16 |
$1.15 |
|
|
| 18 | L-WHT008638 | O-Ring |
$1.28 |
|
|
| 19 | L-N10599502 | Hexalobular Socketm5X20 |
$0.85 |
|
|
| 19 | L-N10599501 | Hexalobular Socket Pan Head Screw |
$1.28 |
|
|
| 20 | L-0P2109003K | Camshaft |
$688.12 |
|
|
| 25 | L-06M109307E | Thrust Bearing |
$6.27 |
|
|
| 26 | L-06M109257T | Control Valve |
$104.44 |
|
|
| 27 | L-06M109087K | Camshaft |
$417.74 |
|
|
| 27 | L-06M109088K | Camshaft |
$417.74 |
|
|
| 28 | L-06M109235 | Seal |
$10.50 |
|
|
| 29 | L-06M109493D | Plate |
$25.35 |
|
