Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | L-4M0407151R | Track Control Arm |
$331.80 |
|
|
| 1 | L-4M0407152R | Track Control Arm |
$331.80 |
|
|
| 3 | L-4M0407181 | Bonded Rubber Mounting |
$42.94 |
|
|
| 4 | L-WHT007028 | 12 Point Bolt Cm12X1.5X100X80 |
$7.59 |
|
|
| 5 | L-WHT001987 | Prev.Torque Hex. M12X1.5 |
$2.40 |
|
|
| 6 | L-WHT006151 | Hexagon Flange Nutm14X1.5 |
$3.86 |
|
|
| 7 | L-4M0407693F | Guiding Control |
$445.12 |
|
|
| 7 | L-4M0407694F | Guiding Control |
$440.45 |
|
|
| 8 | L-4M0407183B | Hydro-Mounting |
$88.79 |
|
|
| 9 | L-N10817601 | Duo Hexagon Flangeam12X1.5X140 |
$10.40 |
|
|
| 10 | L-4M0407505C | Control Arm,Front |
$92.76 |
|
|
| 10 | L-4M0407505G | Control Arm,Front |
$266.37 |
|
|
| 10 | L-4M0407506G | Control Arm,Front |
$266.37 |
|
|
| 11 | L-4M0407510G | Control Arm,Rear |
$255.27 |
|
|
| 11 | L-4M0407509G | Control Arm,Rear |
$255.27 |
|
|
| 12 | L-4M0407515A | Bearing |
$36.68 |
|
|
| 13 | L-N91221601 | Hexagon Flange M10X85-S22 |
$5.14 |
|
|
| 15 | L-WHT006542 | Hexagon Flange |
$7.59 |
|
|
| 16 | L-N10272302 |
Prev.Torque Type M10
|
$2.16 |
|
|
| 18 | L-4M0407253M | Steering Knuckle |
$538.59 |
|
|
| 18 | L-4M0407254M | Wheel Bearing Housing |
$538.59 |
|
|
| 19 | L-WHT006151 | Hexagon Flange Nutm14X1.5 |
$3.86 |
|
|
| 20 | L-4M0407689C | Bearing |
$101.76 |
|
|
| 21 | L-N10241507 | Hexagon Flange |
$4.03 |
|
|
| 22 | L-4M0407613 | Wheel Hub |
$1,401.96 |
|
|
| 23 | L-4M0407625D | Angular Contact |
$171.74 |
|
|
| 24 | L-WHT006966 | Triple Square Bolt |
$4.97 |
|
|
| 25 | L-8E0407643A |
Hexagon Head Bolt M16X72
|
$11.39 |
|
|
| 26 | L-4M0413037J | Shock Absorbing Variante Eaws |
$177.58 |
|
|
| 26 | L-4M0413038J | Shock Absorbing Variante Eaws |
$177.58 |
|
|
| 28 | L-N10272202 | Hexagon Head Bolt M12X1.5X95-S20 |
$6.78 |
|
|
| 29 | L-N10106402 |
Prev.Torque Type M12X1.5
|
$2.28 |
|
|
| 30 | L-N10784702 |
Hexagon Flange M12X1.5X85
|
$6.43 |
|
|
| 31 | L-WHT001987 | Prev.Torque Hex. M12X1.5 |
$2.40 |
|
|
| 32 | L-4M0411317K | Coupling Rod |
$83.53 |
|
|
| 33 | L-WHT007061 | 12 Point Bolt M10X85 |
$4.61 |
|
|
| 33 | L-WHT007422 | 12 Point Bolt Bm12X1.5X65X45 |
$12.44 |
|
|
| 34 | L-N0150816 | Hexagon Flange Nut |
$2.04 |
|
|
| 34 | L-N10286110 | Prev.Torque Type Hm10 |
$2.16 |
|
|
| 35 | L-WHT007423 | 12 Point Bolt Bm12X1.5X65X45 |
$12.44 |
|
|
| 35 | L-WHT006917 | 12 Point Bolt M10X62 |
$4.15 |
|
|
| 37 | L-4ML498625 | Wheel Bearing With Mounting |
$341.14 |
|
