Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | L-407813613H | Folding-Top |
$3,337.00 |
|
|
| 2 | L-407863405A | Lining |
$1,573.32 |
|
|
| 3 | L-407864401E | Lining,Top Box |
$502.79 |
|
|
| 4 | L-4D0803583B | Plug |
$5.60 |
|
|
| 5 | L-407825402 | Seal,Top Box |
$142.77 |
|
|
| 6 | L-407871353 | Water Drain |
$342.66 |
|
|
| 7 | L-N10553801 | Hex.Head Screw W. |
$1.12 |
|
|
| 8 | L-N90917201 | Pan Head Screw |
$1.57 |
|
|
| 9 | L-400863119 |
Plug
|
$0.34 |
|
|
| 10 | L-N90848003 |
Hexagon Flange M8X18
|
$4.14 |
|
|
| 11 | L-N90847903 | Hexagon Flange M6X15 |
$1.46 |
|
|
| 12 | L-407813999A | Gasket |
$51.57 |
|
|
| 13 | L-407825418 | Gasket |
$4.70 |
|
|
| 14 | L-WHT000757 | Screw |
$4.37 |
|
|
| 15 | L-407813241 | Stop |
$382.97 |
|
|
| 16 | L-407825417 | Gasket |
$3.08 |
|
|
| 17 | L-400825837 | Grommet |
$6.33 |
|
|
| 18 | L-407813953B | Water Drip Tray |
$198.20 |
|
|
| 19 | L-407813954B | Water Drip Tray |
$198.20 |
|
|
| 20 | L-407813921A | Drain Pipe |
$168.53 |
|
