Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | L-400831619B | Guide Rail |
$495.99 |
|
|
| 1 | L-400831620B | Guide Rail |
$495.99 |
|
|
| 2 | L-400837461 | Lift Bar Lh |
$810.91 |
|
|
| 2 | L-400837462 | Lift Bar Rh |
$810.91 |
|
|
| 3 | L-400837933 | Window Guide Seal Bottom,Front |
$34.75 |
|
|
| 3 | L-400837934 | Window Guide Seal Bottom,Front |
$34.75 |
|
|
| 4 | L-400845115A | Triangle Window |
$598.34 |
|
|
| 4 | L-400845116A | Triangle Window |
$598.34 |
|
|
| 5 | L-400845201A | Door Window, Front |
$1,137.92 |
|
|
| 5 | L-400845202A | Door Window, Front |
$1,137.92 |
|
|
| 6 | L-408845299C | Side Window |
$767.16 |
|
|
| 6 | L-408845300C | Side Window |
$767.16 |
|
|
| 7 | L-408845501A | Rear Window Glass |
$1,057.78 |
|
|
| 8 | L-400845099C | Front Window |
$4,177.70 |
|
|
| 9 | L-401959801D | Wiper Motor Lh |
$776.04 |
|
|
| 9 | L-401959802D | Wiper Motor Rh |
$822.16 |
|
|
| 11 | L-8D0857511A | Inner Rear View Mirror |
$106.85 |
|
|
| 12 | L-400837439 | Seal Roof Lh |
$318.29 |
|
|
| 12 | L-400837440 | Seal Roof Rh |
$318.29 |
|
|
| 13 | L-408853703B | Moulding-Roof |
$520.74 |
|
|
| 13 | L-408853704B | Moulding-Roof |
$520.74 |
|
|
| 15 | L-400853929A | Clamp |
$47.18 |
|
|
| 16 | L-8N8853707 | Clips |
$2.02 |
|
|
| 17 | L-N91019701 |
Blind Rivet A3.2X8
|
$0.71 |
|
|
| 18 | L-N90986803 |
Flange Tapping St4.2X13-R
|
$1.18 |
|
|
| 20 | L-400853930A | Spring |
$47.18 |
|
|
| 22 | L-400845235 | Spacer |
$0.55 |
|
|
| 23 | L-N90488004 |
Hexagon Nut W. M6
|
$0.36 |
|
|
| 24 | L-WHT000127 |
Flange Nut M8
|
$14.85 |
|
|
| 25 | L-WHT003112 | Hexagon Flange Nut8200513 |
$0.58 |
|
|
| 26 | L-N90944603 |
Hexalobular Socketm5X12
|
$1.03 |
|
|
| 27 | L-WHT000778 |
Washer 5.3X15X1.5 Iso7093-1
|
$0.54 |
|
|
| 28 | L-8Z0837691C |
Screw Kunststoffschr.D=5
|
$1.24 |
|
|
| 30 | L-WHT001418 | Screw |
$1.41 |
|
|
| 31 | L-8H0845233 | Fixation Part |
$4.78 |
|
|
| 32 | L-8H0845481 | Plate Lh |
$22.04 |
|
|
| 33 | L-N90402503 | Hexagon Flange Nut |
$1.74 |
|
