Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | L-WHT000767 | Tapp.Screw,Csk. |
$0.08 |
|
|
| 2 | L-400035243 | Bracket |
$9.64 |
|
|
| 3 | L-400831707 | Door Seal Inner |
$862.20 |
|
|
| 3 | L-400831708 | Door Seal Inner |
$862.20 |
|
|
| 4 | L-400837967C | Rubbing Strip |
$56.14 |
|
|
| 4 | L-400837968C | Rubbing Strip |
$56.14 |
|
|
| 7 | L-400867131B | Door Tray |
$1,922.86 |
|
|
| 7 | L-400867131C | Door Tray |
$583.02 |
|
|
| 7 | L-400867132B | Door Tray |
$1,922.86 |
|
|
| 7 | L-400867132C | Door Tray |
$583.02 |
|
|
| 8 | L-400867171D | Handle Recess, Carbon Fiber |
$3,168.79 |
|
|
| 8 | L-400867172D | Handle Recess, Carbon Fiber |
$3,168.79 |
|
|
| 9 | L-400867195C | Handle Recess, Carbon Fiber |
$2,630.90 |
|
|
| 9 | L-400867196C | Handle Recess, Carbon Fiber |
$2,630.90 |
|
|
| 10 | L-400867299 | Clip |
$14.97 |
|
|
| 11 | L-401867105G | Door Trim Panel |
$6,979.47 |
|
|
| 11 | L-401867106G | Door Trim Panel |
$6,979.47 |
|
|
| 12 | L-400868099C | Door Handle Recess, Lh Leather |
$3,924.20 |
|
|
| 12 | L-400868099CSK1 | Door Handle Recess, Lh Leather |
$3,924.20 |
|
|
| 12 | L-400868099D | Door Handle Recess, Lh Carbon |
$4,361.75 |
|
|
| 12 | L-400868099F | Door Handle Recess, Lh Leather (Small) |
$3,924.20 |
|
|
| 12 | L-400868099J | Door Handle Recess, Lh Std |
$207.98 |
|
|
| 12 | L-400868100C | Door Handle Recess, Rh Leather |
$3,924.20 |
|
|
| 12 | L-400868100CSK1 | Door Handle Recess, Rh Leather |
$3,924.20 |
|
|
| 12 | L-400868100D | Door Handle Recess, Rh Carbon |
$4,361.75 |
|
|
| 12 | L-400868100F | Door Handle Recess, Rh Leather (Small) |
$3,451.05 |
|
|
| 12 | L-400868100N | Door Handle Recess, Rh Std |
$207.98 |
|
|
| 13 | L-400962107A | Rocker Switch, |
$352.06 |
|
|
| 13 | L-400962107B | Rocker Switch, |
$31.39 |
|
|
| 14 | L-6Y0947411 |
Door Warning Light
|
$25.11 |
|
|
| 15 | L-4B0947415A | Entrance Light |
$17.94 |
|
|
| 16 | L-8N0919238 | Warning Light |
$47.54 |
|
|
| 17 | L-8Z0919242 | Sleeve |
$1.68 |
|
|
| 18 | L-N10613801 | Cyl.Screw Am5X55.0 |
$1.29 |
|
|
| 19 | L-N10544301 | Cyl.Screw |
$0.40 |
|
|
| 19 | L-N10544302 | Pan Head Bolt |
$1.57 |
|
|
| 20 | L-N90526602 |
Snap Nut Clamp
|
$1.03 |
|
|
| 21 | L-WHT002961 | Washer |
$0.33 |
|
|
| 22 | L-N10586401 |
Hexalobular Socketm5X10
|
$0.78 |
|
|
| 23 | L-400867159A | Bracket |
$19.06 |
|
|
| 23 | L-400867160A | Bracket |
$19.06 |
|
|
| 24 | L-N01154012 | Washer |
$0.07 |
|
|
| 25 | L-WHT000756 | Screw |
$0.15 |
|
|
| 26 | L-WHT000778 |
Washer 5.3X15X1.5 Iso7093-1
|
$0.54 |
|
|
| 27 | L-N10621601 |
Hexalobular Socketm4X12
|
$1.91 |
|
|
| 29 | L-0R1400549 | Left Handle Kit |
$147.44 |
|
|
| 29 | L-0R1400550 | Right Handle Kit |
$147.44 |
|
|
| 29 | L-0R1400551 | Left Leather Handle Kit |
$1,362.26 |
|
|
| 29 | L-0R1400551SK1 | Black Leather Handle Kit Lh |
$1,362.26 |
|
|
| 29 | L-0R1400552 | Leather Handle Kit Rh |
$1,362.26 |
|
|
| 29 | L-0R1400552SK1 | Right Black Leather Handle Kit |
$1,362.26 |
|
