Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 6 | L-408971170T | Harness,Stop Light High |
$292.17 |
|
|
| 9 | L-4B9945097A | High-Mounted Stop |
$104.46 |
|
|
| 10 | L-4B9945289 | Cover,Brake Lamp, High Positioned |
$0.26 |
|
|
| 23 | L-N10017304 |
Hexagon Flange Nut M5
|
$1.74 |
|
|
| 24 | L-N10160202 | 6-Point Flange |
$0.53 |
|
|
| 29 | L-400945095P | Rear Combination Lamp |
$2,059.67 |
|
|
| 30 | L-400945096P | Rear Combination Lamp |
$2,059.67 |
|
|
| 31 | L-400813697A | Bracket |
$70.82 |
|
|
| 31 | L-400813698A | Bracket |
$70.82 |
|
|
| 32 | L-408813391E | Mounting Part |
$172.75 |
|
|
| 32 | L-408813392E | Mounting Part |
$364.05 |
|
|
| 33 | L-408863777 | Damping |
$424.34 |
|
|
| 33 | L-408863778 | Damping |
$526.37 |
|
|
| 34 | L-N0116945 | Washer 7.1X22X1.3 |
$0.70 |
|
|
| 35 | L-N01508213 |
Hexagon Flange Nutm6
|
$0.17 |
|
|
| 36 | L-N90847903 | Hexagon Flange M6X15 |
$1.51 |
|
|
| 37 | L-8E0806193 |
Retaining Part Ausgleichteil
|
$14.67 |
|
|
| 38 | L-N01775311 | Bulb |
$6.96 |
|
|
| 39 | L-N10591501 | Bulb |
$6.20 |
|
|
| 40 | L-N10727901 | Bulb |
$48.23 |
|
|
| 41 | L-420945703 | Rear Fog Light |
$144.35 |
|
|
| 42 | L-400937546 | Clutch Carrier |
$3.77 |
|
|
| 43 | L-N10472101 | Fillister-Head |
$1.39 |
|
