Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | L-400616807 | Valve, Brakebooster |
$22.89 |
|
|
| 2 | L-401611971B | Vacuum Hose |
$42.93 |
|
|
| 3 | L-N10201901 |
Ear Hose Clamp 22.6X7X0.6
|
$1.74 |
|
|
| 4 | L-400611936A | Vacuum Pipe |
$53.06 |
|
|
| 5 | L-400611940B | Vacuum Hose |
$174.63 |
|
|
| 6 | L-400611921 | Pipe Union |
$1.68 |
|
|
| 7 | L-N0245097 | Clamp |
$15.22 |
|
|
| 8 | L-400611937C | Tubo Flex 3Vie/Valv.No Ritorno |
$69.63 |
|
|
| 9 | L-400251189E | Clamp |
$12.09 |
|
|
| 10 | L-400611742 | Brake Pressure |
$76.57 |
|
|
| 10 | L-400611742B | Tube |
$76.57 |
|
|
| 11 | L-191611715 | Hose Support 13.50 |
$1.74 |
|
|
| 12 | L-400612173 | Pipe Union |
$1.18 |
|
|
| 13 | L-N10017303 | Hexagon Flange Nut |
$0.39 |
|
|
| 14 | L-400611797 | Bracket |
$15.45 |
|
|
| 15 | L-443131541 | Vacuum Tank Ass. |
$28.88 |
|
|
| 16 | L-400611741 | Brake Pressure |
$65.93 |
|
|
| 16 | L-400611741A | Tube |
$65.93 |
|
|
| 17 | L-400611809 | Connecting Piece |
$35.65 |
|
|
| 18 | L-400611764A | Brake Pressure |
$94.37 |
|
|
| 19 | L-400611763A | Brake Pressure |
$94.37 |
|
|
| 20 | L-400611761A | Hose |
$103.77 |
|
|
| 21 | L-6N0611797D | Bracket |
$6.10 |
|
|
| 22 | L-400611762A | Brake Pressure |
$94.37 |
|
|
| 23 | L-400611724 | Brake Pressure |
$43.38 |
|
|
| 24 | L-400611939A | Hose |
$42.65 |
|
|
| 26 | L-N10171105 | Hexagon Flange Bolt |
$1.29 |
|
|
| 27 | L-400121220D | Damping Profile |
$45.84 |
|
|
| 29 | L-410616807 | Valve |
$29.78 |
|
|
| 31 | L-1J0611853 | Spacer 1X4.80 |
$0.84 |
|
|
| 32 | L-400121097A | Retainer |
$11.42 |
|
|
| 33 | L-N01508213 |
Hexagon Flange Nutm6
|
$0.17 |
|
|
| 34 | L-400611799 | Bracket,Brake Hose |
$0.63 |
|
|
| 35 | L-8Z0611797C | Bracket |
$1.51 |
|
