Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 2 | L-N01020717 | Hexagon Head Bolt |
$1.09 |
|
|
| 3 | L-WHT000769A | Spring Lock Washer |
$0.73 |
|
|
| 4 | L-WHT001187 | Washer 10X5.3X1 Uni 6952 Cat-A |
$0.67 |
|
|
| 6 | L-WHT001197A |
Washer
|
$0.23 |
|
|
| 7 | L-07L133063A | Throttle Valve |
$2,292.37 |
|
|
| 10 | L-07M133074 | Throttle Body Gasket |
$54.81 |
|
|
| 12 | L-WHT001514 | Spring Washer |
$20.64 |
|
|
| 13 | L-07M919529 | Coolant Temperature Sensor |
$237.58 |
|
|
| 14 | L-07M133433A | Cover |
$1,702.58 |
|
|
| 15 | L-07M129717A | Alimentation Manifold Gasket |
$122.96 |
|
|
| 16 | L-07M133155 | Gasket |
$91.36 |
|
|
| 17 | L-07M133684 | Flange |
$60.87 |
|
|
| 18 | L-WHT003091 | Screw M5X16 Uni 5933/Z Black |
$0.72 |
|
|
| 19 | L-07M919529A | Sensor |
$368.34 |
|
|
| 20 | L-07M919327 | Pressure Sensor Support |
$53.47 |
|
|
| 21 | L-N01020717 | Hexagon Head Bolt |
$1.09 |
|
|
| 22 | L-WHT001187 | Washer 10X5.3X1 Uni 6952 Cat-A |
$0.67 |
|
|
| 23 | L-WHT000769A | Spring Lock Washer |
$0.73 |
|
|
| 24 | L-07M133644 | Pipe |
$105.16 |
|
|
| 25 | L-07M133643 | Pipe |
$155.79 |
|
|
| 28 | L-07M133211 | Flange |
$54.86 |
|
|
| 29 | L-07M133026 | Gasket |
$58.42 |
|
|
| 30 | L-07M129734 | Spacer Between Induction Maniffold And C |
$28.32 |
|
|
| 32 | L-490147001 | Collett.Aspir.Vern.Murcielago |
$5,903.40 |
|
|
| 35 | L-07M129734A | Spacer Between Induction Manifold And Co |
$28.32 |
|
|
| 38 | L-07M133100 | Cap |
$53.30 |
|
|
| 39 | L-07M133075 | Throttle Cover Gasket |
$31.60 |
|
|
| 40 | L-07M131611A | Pipe |
$102.71 |
|
|
| 40 | L-07M131612A | Pipe |
$102.71 |
|
|
| 41 | L-07L115707 | Union |
$54.25 |
|
|
| 42 | L-400127217 | Securing Clip |
$0.33 |
|
|
| 43 | L-07M131849 | Pipe |
$102.71 |
|
|
| 43 | L-07M131850 | Pipe |
$102.71 |
|
|
| 45 | L-07M133615 | Reference Pin 6H6X12C40 |
$7.29 |
|
|
| 47 | L-07M906287 | Bracket |
$42.06 |
|
|
| 50 | L-07M131846 | Pipe |
$102.71 |
|
|
| 50 | L-07M131847 | Pipe |
$102.71 |
|
|
| 51 | L-400251189E | Clamp |
$12.02 |
|
|
| 52 | L-07M133119 | Intake Manifold Pipeinlet |
$57.75 |
|
|
| 53 | L-N0138481 | Washer |
$0.57 |
|
|
| 56 | L-410905131 | Bracket |
$23.20 |
|
|
| 57 | L-410911085 | Starter Cable Fast. Bracket |
$13.46 |
|
|
| 58 | L-07M115113 | Union |
$68.99 |
|
|
| 59 | L-07M103545 | Taper Plug 12X1.5X10 |
$2.23 |
|
