Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | L-400998075 | Secondary Air Pump |
$525.15 |
|
|
| 2 | L-N10451408 |
Hexalobular Socket M6X16
|
$1.52 |
|
|
| 3 | L-N10210501 |
Clamp
|
$1.40 |
|
|
| 4 | L-N02214812 | Hex.Head Clamping |
$1.87 |
|
|
| 5 | L-WHT002961 | Washer |
$0.34 |
|
|
| 6 | L-N91054001 | Hexalobular Socketm6X22-S11 |
$1.28 |
|
|
| 7 | L-N10451408 |
Hexalobular Socket M6X16
|
$1.52 |
|
|
| 8 | L-470131611B | Hose |
$618.51 |
|
|
| 9 | L-470131611C | Hose |
$618.51 |
|
|
| 10 | L-N0206253 | Holding Clip |
$1.69 |
|
|
| 11 | L-06A131120D | Gasket |
$7.00 |
|
|
| 12 | L-470906613D | Bracket,Sap |
$39.74 |
|
|
| 13 | L-470906617C | Bracket,Sap Pompa Aria Sec |
$21.30 |
|
|
| 14 | L-07L131119 | Adapter |
$14.59 |
|
|
| 15 | L-07L131101F | Combination Valve |
$150.54 |
|
|
| 16 | L-470133898A | Tube,Secondary Air |
$169.22 |
|
|
| 17 | L-470133897B | Tube,Secondary Air |
$175.05 |
|
|
| 18 | L-07L133579 | Branch Tube |
$6.94 |
|
|
| 19 | L-470131845 | Hose |
$85.89 |
|
|
| 20 | L-470131846 | Hose |
$40.20 |
|
|
| 21 | L-470131853 | Hose |
$17.51 |
|
|
| 23 | L-07M133106B | Heat Shield |
$90.44 |
|
|
| 25 | L-470906325A | Retaining Part |
$39.56 |
|
|
| 26 | L-470906294A | Retaining Part |
$90.21 |
|
|
| 27 | L-1J0906029A | Clip |
$6.83 |
|
|
| 28 | L-WHT001825A | O-Ring |
$0.85 |
|
