Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | L-470901127B | Motor |
$2,359.38 |
|
|
| 1 | L-470901127C | Motor Side Flap |
$2,127.50 |
|
|
| 2 | L-470901099B | Bracket |
$220.29 |
|
|
| 2 | L-470901100B | Bracket |
$220.29 |
|
|
| 4 | L-470903125B | Bracket Actuator Guide |
$336.23 |
|
|
| 5 | L-470903121 | Bracket |
$40.75 |
|
|
| 6 | L-470901111 | Gasket |
$4.23 |
|
|
| 7 | L-N01508210 |
Hexagon Flange Nutm6
|
$1.80 |
|
|
| 8 | L-470813353 | Insert Part |
$33.91 |
|
|
| 9 | L-470813354A | Insert Part |
$26.84 |
|
|
| 10 | L-470813583B | Plug |
$35.30 |
|
|
| 11 | L-470814641 | Pivot Pin |
$57.04 |
|
|
| 12 | L-N10558102 |
Hexalobular Socket
|
$3.65 |
|
|
| 13 | L-N10569501 |
Hexalobular Socketm5X16
|
$2.14 |
|
