Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-201935 | F1 Gearbox Kit With Sensors |
$345.91 |
|
|
| 2 | M-207447 | Sensor Mount On Clutch Contr |
$206.70 |
|
|
| 3 | M-14303324 | Socket Head Screw M 4X 20 |
$2.94 |
|
|
| 4 | M-10519224 | Split Washer.D. 4.30- 9 X 0 |
$20.07 |
|
|
| 5 | M-14304424 | Socket Head Screw M 5X 25 |
$3.92 |
|
|
| 6 | M-10519378 | Split Washer.D. 5.30-10 X 1 |
$1.72 |
|
|
| 7 | M-980001158 | Position Sensor Kit Dx001747 |
$1,033.77 |
|
|
| 8 | M-10441190 | Bracket With Sheath |
$1.11 |
|
|
| 9 | M-14058411 | Nut |
$1.72 |
|
|
| 10 | M-203294 | Pressure Sensor |
$437.10 |
|
|
| 11 | M-140605 | O-Ring D.8X1.5 |
$9.51 |
|
