Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 2 | M-216285 | R.H. Cylinders Head Cover |
$245.73 |
|
|
| 3 | M-198927 | Rh Head Cover Gasket |
$57.41 |
|
|
| 4 | M-14304424 | Socket Head Screw M 5X 25 |
$3.97 |
|
|
| 5 | M-14497878 | Split Washer D. 5.30X9.55 |
$1.07 |
|
|
| 6 | M-185276 | Rh Wiring Small Cover |
$49.00 |
|
|
| 7 | M-156830 | Socket Head Screw M 6X 40 |
$3.97 |
|
|
| 8 | M-200414 | Stud M6X25.5(M)-M6X11(F) |
$13.76 |
|
|
| 9 | M-187710 | Wiring And Cover Fastening S |
$9.39 |
|
|
| 10 | M-11197774 | Washer |
$2.26 |
|
|
| 11 | M-204102 | Stud M6X25(M)-M6X10(M) H |
$14.38 |
|
|
| 12 | M-184966 | Rh Head Gasketcrankcase |
$78.90 |
|
|
| 13 | M-14326001 | Threaded Plug For Gearbox |
$1.14 |
|
|
| 15 | M-183447 | Tapered Threaded Plug M18X1. |
$6.55 |
|
|
| 16 | M-223982 | Spark Plug Sleeve Gasket |
$4.64 |
|
|
| 17 | M-164400 | Tapered Threaded Plug D.16X1 |
$6.71 |
|
|
| 18 | M-13541224 | Stud M6X12 Stem 22 |
$44.01 |
|
|
| 19 | M-199760 | Tapered Threaded Plug 6X1 |
$1.54 |
|
|
| 20 | M-134233 | O-Ring D. D. 18.77- 8X 100 |
$7.31 |
|
|
| 21 | M-102725 | Centring Dowel D.8X8 |
$1.75 |
|
|
| 22 | M-14305621 | Screw |
$1.74 |
|
|
| 23 | M-11197774 | Washer |
$2.26 |
|
|
| 26 | M-13543424 | Stud M8X16 Stem 28 |
$1.74 |
|
|
| 27 | M-187963 | Plug |
$5.21 |
|
|
| 28 | M-184681 | Oil Pressure Check Valve |
$94.62 |
|
|
| 30 | M-10263360 | Gasket 20- 26X 1 |
$1.00 |
|
