The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-189215 | A.C.Condenser. |
€460,70 |
|
|
| 2 | M-199515 | R.H.Upper Bracket. |
€36,98 |
|
|
| 3 | M-199672 | R.H.Lower Bracket. |
€7,18 |
|
|
| 4 | M-199516 | L.H.Lower Bracket. |
€15,73 |
|
|
| 5 | M-165137 | Screw |
€1,58 |
|
|
| 6 | M-67085100 | Dehydrating Filter |
€35,87 |
|
|
| 7 | M-68668700 | Pipe From Condenser To Filte |
€99,45 |
|
|
| 8 | M-67579900 | Clip. |
€0,95 |
|
|
| 9 | M-67306300 | Pipe From Joint To Condenser |
€77,61 |
|
|
| 10 | M-67060400 | Complete Dehydrating Filter |
€15,73 |
|
|
| 11 | M-16287127 | Screw. |
€1,86 |
|
|
| 12 | M-11612524 | Screw. |
€2,50 |
|
|
| 13 | M-69627900 | Pipe From Compressor To Cond |
€278,80 |
|
|
| 14 | M-69666400 | Pipe From Compressor To Shie |
€346,80 |
|
|
| 15 | M-379290721 | Clip |
€1,30 |
|
|
| 16 | M-284728 | AC Delphi Compressor |
€2.069,75 |
|
|
| 17 | M-141496 | Spacer Bet.Actuator And Gear |
€11,04 |
|
|
| 18 | M-175428 | Socket Head Screw M8X120 |
€9,02 |
|
|
| 19 | M-14307124 | Socket Head Screw M 8X 90 |
€15,46 |
|
|
| 20 | M-11193874 | Washer |
€1,15 |
|
|
| 21 | M-227256 | Bracket |
€27,97 |
|
|
| 22 | M-67063200 | Clip. |
€3,13 |
|
|
| 23 | M-67306500 | Pipe From Filter To Shield. |
€325,55 |
|
|
| 24 | M-65628200 | Pressostat |
€123,25 |
|
|
| 25 | M-14305424 | Screw |
€1,46 |
|
|
| 26 | M-12601274 | Washer |
€1,15 |
|
|
| 27 | M-14305724 | Screw |
€1,46 |
|
|
| 28 | M-127494 | Washer |
€1,15 |
|
|
| 29 | M-68392000 | O-Ring 0691154 |
€6,16 |
|
|
| 30 | M-68392100 | O-Ring 069861 |
€4,17 |
|
|
| 31 | M-66309700 | O-Ring 069862 |
€15,73 |
|
|
| 32 | M-68392700 | O-Ring 0691177 |
€3,13 |
|
|
| 33 | M-68392800 | O-Ring 0691178 |
€4,88 |
|
|
| 34 | M-66309800 | O-Ring 069863 |
€15,73 |
|
|
| 35 | M-66309600 | O-Ring 069579 |
€15,73 |
|
|
| 36 | M-67085400 | Or Gasket For 7Cvc Compr. (D |
€20,79 |
|
|
| 37 | M-67085300 | Or Gasket For 7Cvc Compr. (I |
€20,79 |
|
|
| 38 | M-68199800 | Bracket |
€12,42 |
|
|
| 39 | M-16297627 | Screw. |
€2,09 |
|
|
| 40 | M-222959 | Bracket |
€128,80 |
|
|
| 41 | M-14305724 | Screw |
€1,46 |
|
|
| 42 | M-11197774 | Washer |
€1,89 |
|
|
| 43 | M-80964400 | Flange |
€17,11 |
|
|
| 44 | M-80964500 | Gasket |
€4,38 |
|
|
| 45 | M-14040611 | Nut |
€1,46 |
|
